High Temperature System Can accept an externally supplied water source heated up to a maximum of 85°C/185°F COMMERCIAL SERIES
5.0 HP Baldor motor delivers energy efficiency and reliability suited for commercial applications.
Direct drive system connects the engine to the pump for a compact and efficient power transfer.
Commercial grade General triplex pump featuring die-cast body, forged brass manifold, solid ceramic plungers. Special plating and seals to handle rigorous temperatures.
External unloader provides enhanced pump cooling.
Accessories include high-pressure hose, spray gun wand assembly, and spray nozzles so that it can be used right out of the box.
Powder coated steel frame mounts securely to a wall with storage for accessories including a hose reel for the high pressure hose.
Does not include power plug. Needs to be wired in by a certified electrician.
Product Specifications
Before we get into the technical specs here is a brief explanation of the PSI (pounds per square inch) and GPM (gallons per minute) ratings: these are the key to understanding the cleaning power and efficiency of a pressure washer as they determine how well the machine can handle commercial cleaning tasks.
Performance
-
Pressure: 2,000 PSI
-
Flow Rate: 4.0 GPM
-
Max Inlet Water Temp: 85°C / 185°F
To explain the importance of these ratings the PSI and GPM values determine the effectiveness of the pressure washer for different cleaning applications for optimal results for light and heavy duty jobs.
Motor
-
Brand: Baldor
-
Power: 5.0 HP
-
Phase: Single-phase
-
Type: Continuous-duty industrial-grade motor
-
Wiring: Hardwired installation required (no plug or switch included)
Pump
-
Brand: General Pump
-
Type: Triplex plunger
-
Manifold: Forged brass
-
Plungers: Solid ceramic
-
Features: High temp components, thermal protection
-
Unloader: External for pump cooling, pressure tuning and seal life
Frame
-
Material: Powder coated steel
-
Design: Wall mount with built in hose reel and storage
Accessories Included
-
Hose: 50 ft. high pressure, twin wire braided
-
Spray Gun: Insulated with 36” commercial grade wand
-
Nozzles: 5 quick connect tips (0°, 15°, 25°, 40° and Soap)
This unit is not ready to use right out of the box and requires a Plug, Cord & Switch to be installed.
It comes equipped with a built-in bypass/re-circulating hose (which can be bypassed if desired) and DOES include a flow switch & automatic on/off box.
⚡ Important: Any alterations, repairs, or installations on electric pressure washing units must be performed by a certified electrician.
Download Specsheet Here
Download Manual Here
SKU: X-2050FW1GENHT
