High Volume/Low Pressure Skid W/ High Flow Proportioner

Regular price
$19,149.99
Sale price
$19,149.99
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

Honda GX200 and Comet P40 Pump (11GPM) Option:

This unit is designed to give you a max of 11GPM at 300PSI with the ability to adjust the flow and pressure using the built-in regulator. It is also ready to run dual guns with the two ball valves at the pump if desired. Just add a second line and you have 2 guns at 5.5GPM per gun.

  • High Flow Proportioner
  • Heavy Duty Aluminum Skid with Vibration Isolating Rubber Feet
  • Honda GX200 engine with electric start
  • Comet P40 Pump
  • Slotted PVC filters
  • 18" Full Frame Water Dragon Reel with Stainless Manifold on Custom Hose Reel Rack
  • 300' 1/2" Orange AG Hose
  • 12" Full Frame Water Dragon Reel with Stainless Manifold on Custom Hose Reel Rack
  • 100' 3/4" Garden Hose
  • 2 - 100 gallon slim line tanks
  • 2 - 7 gallon soap tanks
  • 4 nozzle holder with #60 0, 15, 25, 40-degree nozzles
  • 20" stainless steel lance with quick connects
  • Plastic body chemical applicator gun with Viton seals
  • Suction and Discharge line included

Mounted on 60" x 56" aluminum diamond plate skid.

"Measurements"

  • 56" Tall
  • 60" Wide (Looking straight at it)
  • 64" Deep
  • When you add the handles on the hose reels the overall left to right measurement is: 66"
"Weights"
  • Empty - 800lbs
  • Full - 3050lbs

*Shipping cost calculated at checkout*
*FREE Local Pickup in Langley, B.C.*

GX200 Manual



Honda GX1600 and Udor Zeta 40P/GR Pump (10GPM) Option:

This unit is designed to give you a max of 10GPM at 300PSI with the ability to adjust the flow and pressure using the built-in regulator. It is also ready to run dual guns with the two ball valves at the pump if desired. Just add a second line and you have 2 guns at 5GPM per gun.

  • High Flow Proportioner
  • Heavy Duty Aluminum Skid with Vibration Isolating Rubber Feet
  • Honda GX160 engine with electric start
  • Udor Zeta 40P/GR Pump with Pressure and Flow Regulator (this poly pump will help stand up to the harmful effects of bleach)
  • Slotted PVC filters
  • 18" Full Frame Water Dragon Reel with Stainless Manifold on Custom Hose Reel Rack
  • 300' 1/2" Orange AG Hose
  • 12" Full Frame Water Dragon Reel with Stainless Manifold on Custom Hose Reel Rack
  • 100' 3/4" Garden Hose
  • 2 - 100 gallon slim line tanks
  • 2 - 7 gallon soap tanks
  • 4 nozzle holder with #60 0, 15, 25, 40-degree nozzles
  • 20" stainless steel lance with quick connects
  • Plastic body chemical applicator gun with Viton seals
  • Suction and Discharge line included

Mounted on 60"x56" aluminum diamond plate skid, plumbed with two 55 gallon chem tanks.

"Measurements"

  • 56" Tall
  • 60" Wide (Looking straight at it)
  • 64" Deep
  • When you add the handles on the hose reels the overall left to right measurement is: 66"
"Weights"
  • Empty - 800lbs
  • Full - 3050lbs
Lead times on this product vary. Contact us for details.
Restocking fee applies to any cancelled orders after initial purchase.

*Shipping cost calculated at checkout*

*FREE Local Pickup in Langley, B.C.*











SKU: WD-5407CMS-PP
